Adjustable working force: 40 - 400 tons
Clearance between columns on the operator's side: approximately 2,400 mm
Clearance between side columns: approximately 1,800 mm
Maximum work surface: 2,400 mm x 2,400 mm
Mobile table travel: approximately 1,800 mm
Clearance between open work surfaces: approximately 2,000 mm
Work surface height from the ground: approximately 800 mm
Approach speed: approximately 100 mm/sec
Working speed: approximately 0 - 5 mm/sec
Return speed: approximately 100 mm/sec
Total press height: approximately 6,800 mm
Installed motor power: approximately 50 kW
Code 2511
